STM32F030C8T6 bukan STM32F103C8T6 ARM STM32 Development Board

STM32F103C8T6 ARM STM32 Minimum System Development Board Module

Microcontroller features

• STM32F103C8T6 in LQFP48 package
• ARM®32-bit Cortex®-M3 CPU
• 72 MHz max CPU frequency
• VDD from 2.0 V to 3.6 V
• 64 KB Flash
• 20 KB SRAM
• GPIO (32) with external interrupt capability
• 12-bit ADC (2) with 10 channels
• RTC
• Timers (4)
• I2C (2)
• USART (3)
• SPI (2)
• USB 2.0 full-speed
• CAN

Board features

• Small foot-print
• Flexible board power supply: USB VBUS or external source (3.3V, 5V)
• User LED: LED1
• One push button: RESET
• Programming/Debug port
• Micro-B USB connector
